Combination PRO ride-on sweeper scrubber drier.

When the most powerful scrubbing machine is also the most efficient sweeping machine

GMG Combinata brings together the strength of a real sweeper with the power of a big scrubber dryer. With a single machine, you can do the work of two, halving the time and costs of each cleaning operation, labour and management.

It is designed for large environments where high performance and productivity are crucial, such as large factories, logistics centres, warehouses, parking lots, train stations, airports, shopping malls and exhibition centres.


IT'S POWERFUL

Increase productivity, by cleaning with greater power and 30% faster than a conventional model of the same category

Double productivity, carrying out the work of a sweeping machine and a scrubbing machine in just one pass

Increase productivity, by cleaning ramps with slopes up to 20% at full load

Increase productivity, with the possibility to install batteries of different technologies, from lead acid batteries to advanced lithiumion ones, which provide up to 7 hours of run time on a single charge

Increase operator productivity, with enhanced control over tasks provided by the touch screen display and the rear view camera

Increase operator productivity, providing up to 9 pre-set cleaning programs according to different applications

Halve costs: by purchasing just one machine that can carry out two types of cleaning in a single operation, you can halve your investment and labour costs


IT'S EASY

Reduce operator training, with on-board video tutorials which show how to perform common operation and maintenance activities

Increase uptime, with easy and intuitive access to key features through the iD – Intelligent Drive system

Halve operation time: now, you can collect solid waste and scrub the floor in a single operation

Enhance control over cleaning results, with pre-set work programs and supervisor controls that ensure proper machine setting and use by the operator

Reduce service time and cost, with fully accessible design that enables easy and quick servicing


IT'S ECO-FRIENDLY

Reduce the use of resources, saving water, chemical and energy thanks to Fimap sustainable technologies

Reduce the environmental impact, with constant control of the CO₂ produced

Reduce water use up to 66% with FLR - Fimap Long Range technology, that allows you to clean more sq.m with the same amount of resources

GMG Combinata can be provided in in Pro or Plus configuration, both of them can be customized to meet more specific needs thanks to the many accessories available.

JUST ONE MACHINE FOR TWO TASKS
With a single machine, you can do the work of two, halving the time and costs of each cleaning operation, labour and management. The GMG Combinata does the work of a sweeping machine and a scrubbing machine in just one pass. With the GMG Combinata, you can keep your spaces clean and ensure productivity for the price of a single machine, a single operation, and a single operator.

WHY CHOOSE AN ELECTRIC MACHINE?
Unlike many models in its class, the GMG Combinata is not powered by an endothermic engine, but rather by batteries. This is a much more efficient solution, due to the fact that there is no energy loss. Combustion engines, which generate heat through the combustion of fuel, inevitably lose much of the energy produced. The energy which remains - the kinetic energy, which makes the machine run and the engine components move - is much less. In an electric motor, meanwhile, which does not need to warm up to reach maximum revs, the energy generated can all be used immediately, without any dispersion.

The use of an electrical power supply offers unique benefits such as:-
• no fuel costs.
• zero exhaust emissions.
• silent operation.
• vibrations reduced to a minimum.
• greater safety for the operator.
• the versatility of being able to use the machine indoors.

SWEEPING UNIT
Two side sweeping brushes collect coarse dirt and solid waste on a 1700 mm working path. The cylindrical brushes remove the last residue of dirt before the final scrubbing and drying action carried out by the scrubbing unit.

The GMG Combinata is available with a panel filter for standard applications, or can be ordered with a cloth pocket filter for optimal filtration results, even in environments where the presence of fine dust is very high. Even higher filtration performance can be achieved with the Tetratex® pocket filter. This is made with a microporous expanded PTFE membrane, a highly efficient material that is ideal for particularly difficult applications, such as in areas where minerals, chemical products, pharmaceutical substances and fertilisers are processed, as well as in the food industry. The Tetratex® membrane has an excellent release capacity, courtesy of its surface filtration technology: once it reaches the surface, dust - even the most adherent - falls down, leaving the filter free and preventing clogging.

DUAL 3-STAGE VACUUM MOTOR
The high vacuuming power provided by the dual 3-stage vacuum motor ensures perfect drying in one single pass, making the floor immediately available and safe, preventing the risk of slipping.

PERFECTLY DRY FLOOR IN ONE SINGLE PASS
The layout of the squeegees helps to collect water and direct it towards the suction point, thus ensuring better drying. The floor is perfectly dried even in bends, thanks to the lateral movement of the rear squeegee, which always follows the course of the machine.

INCREASE PRODUCTIVITY
• by cleaning with greater power and 30% faster than a conventional model of the same category
• by carrying out the work of a sweeping machine and a scrubbing machine in just one pass
• with the possibility to install batteries of different technologies, from lead acid batteries to advanced lithium-ion ones, which provide up to 7 hours of run time on a single charge.

REAR-WHEEL TRACTION WITH 2 INDEPENDENT MOTOR WHEELS
The rear-wheel traction with 2 electronically-controlled independent wheels provides the GMG Combinata with the necessary power to easily drive up ramps of up to 20% whilst working. In a multistorey car park, the GMG Combinata is therefore able to move easily from one level to another, guaranteeing high-level grip when climbing, along with reliability and maximum control when manoeuvring.

GREATER SCRUBBING POWER FOR THE MOST STUBBORN DIRT
GMG Combinata’s brush pressure can be increased up to 250 kg, to easily remove even the adherent dirt, saving time.

SAVE RESOURCES AND INCREASE PRODUCTIVITY
GMG Combinata can be equipped with the exclusive FLR – Fimap Long Range that filters the collected cleaning solution so that it can be used again. This increases the amount of resources available for the intervention and, as a consequence, the sq.m cleaned. Reusing the detergent solution reduces water and chemical consumption and eliminates the time required to empty and fill up the tanks. As a result, productivity can be increased by up to 70%.

MINIMUM AISLE TURN
Combination of rear-wheel traction and independent motor wheels allows a small turning radius, which remains within the machine diagonal of 3135 mm. As a result, the space required for manoeuvring is also minimal. The friction that is usually generated in reversing causes a significant consumption of energy, which negatively affects the working range. The action of the independent rear motor wheels together with the double front wheel of GMG Combinata considerably reduces the friction produced when steering. This avoids unnecessary energy dispersion, extends battery run time and increases productivity.

POWER STEERING PROVIDES COMFORT
The power steering makes the steering wheel lighter, increases manoeuvrability and reduces the operator fatigue while driving.

BRUSHLESS MOTORS
Motors without brushes bring several advantages:

More power,
which is entirely used avoiding the dispersion that is normally caused by the friction of the brushes

Greater durability over time,
as they do not generate heat, there is no need for ventilation which can cause damaging seepages.

Compact design,
they leave more space to the volume of the tanks, thus increasing the working autonomy.

Greater control,
which being electronic, and not electromechanical, automatically adjusts to the required performance, improving efficiency.

No maintenance,and extremely longer life cycle.

CORROSION RESISTANT COMPONENTS
All of the components close to the floor - and therefore in contact with water - are corrosion-proof.

FULL PROTECTION
Its design has been conceived to provide a full protection. The comfortable and safe driver’s seat improves visibility and control for the user during manoeuvres. Since there are no protruding parts, the machine blends safely into the environment. Long-lasting, rotationally moulded plastic tanks and steel wrap-around bumper protect mechanical components, while sensors prevent potential collisions by warning when approaching an obstacle.

The roller bumpers at the 4 corners deflect shocks protecting the machine and extending its life.

IT IS FULLY ACCESSIBLE, TO FACILITATE EXTRAORDINARY MAINTENANCE
The functional design of the machine enables full access to the parts that require maintenance, thus reducing operation times and costs.

ANTI-COLLISION SYSTEM
The anti-collision system helps manoeuvring safely, warning when the machine is approaching an obstacle. The front and rear sensors make two different sounds. While the machine is moving the operator can recognise by the sound whether the obstacle is in the front or in the rear of the machine. In the Plus versions, in addition to the sound, the level of approach to the obstacle can also be viewed on the display. The front sensors are automatically activated when the machine drops below a certain speed during forward travel.

ACTIVE TECHNOLOGIES TO PREVENT ACCIDENTS

REAR VIEW CAMERA
GMG Combinata’s rear view camera makes it safer to manoeuvre in cluttered environments, with shelving, machinery or goods stored on the ground, as it may occur in warehouses and logistics centres. In addition, it enables to check cleaning performance anytime, without looking away from the direction of driving.

TOUCHSCREEN DISPLAY
Enhances visibility in dim light
Digital touch screen display creates a modern and technological environment that displays information in high resolution. The side control panel provides easy access to functions, allowing the operator to work on settings without getting distracted.
